Çıkış Gücü

300W

Working mode

PWM

Çıkış

Output voltage

DC 0~100% full range adjustable

Output current

DC 0~100% full range adjustable

O.V.P. range

DC 1~100% rated output

O.C.P. range

DC fixed 105% max. output

Hat regulation

CV≤0.2% +2 digits

CC≤0.5% +2 digits

Yük regulation

≤0.5% +2 digits

Ripple & Noise

≤1% rms full scale

Ekran

Voltmeter

4 digits LED display

Ammeter

4 digits LED display

Voltage resolution

0.000-9.999V; 00.00-99.99V; 000.0-999.9V

Current resolution

0.000-9.999A; 00.00-99.99A; 000.0-999.9A

Accuracy

±(1% FS+1 digit)

Opsiyonel Özelikler

Display meter

4 1/2 digits LED display (Max. display 19999)

Output terminal

On front panel; or on rear panel; or on both front and rear panels

Output ON/OFF

Front panel switch

Terminal block or Wires on rear panel for remote control

Genel koşullar

Koruma

Over voltage, over current, over temperature and over load protections

Çalışma koşulları

0°C~40°C, <80%RH

Depolama Koşulları

-10°C ~70°C, <80%RH

Giriş gücü

AC110V/220V±10%, 50/60Hz

Giriş

Power socket or terminal block

Boyutları (WxHxD)

200x150x285mm (M chassis, 200W~1250W)

260x160x380mm (L chassis, 500W~2500W)

260x160x440mm (XL chassis, 2250W~6kW)
