Sabit Voltajlı İşlem

Line regulation

≤0.01%+3mV

Load regulation

≤0.01%+3mV (I≤3A); ≤0.02%+5mV (I>3A)

Ripple & Noise (5Hz~1MHz)

≤1mVrms (I≤3A);≤2mVrms (I>3A)

Constant current operation

Line regulation

≤0.2%+3mA

Load regulation

≤0.2%+3mA (I≤3A); ≤0.2%+5mA (I>3A)

Ripple & Noise

≤3mArms (I≤3A); ≤6mArms (I>3A)

Tracking operation

Parallel

Line regulation

≤0.01%+3mV

Load regulation

≤0.01%+3mV (I≤3A); ≤0.02%+5mV (I>3A)

Series

Line regulation

≤0.01%+5mV

Load regulation

≤300mV

Tracking error

≤0.5%+10mV of the master, no load (with load, add load regulation≤300mV)

Display

Accuracy

Real voltage and current output: ±(1% reading+2 digits)

Preset voltage and current: ±(1%reading+8 digits)

General

Insulation

Between base and output terminal: ≥20MΩ/500VDC

Between base and AC power cord:≥300MΩ/500VDC

Operating environment

0℃~40℃, ≤80%RH

Storage environment

-10℃~70℃, ≤70%RH

Power source

AC110V/220V±10%, 50/60Hz

Accessories

Power cord x1, Operation manual x1
